– the guide rollers
– the measured material
– the readings
If process material differs significantly from the SCHMIDT calibration material in diameter, rigidity or shape, special calibration using customer supplied samples is recommended. For this purpose a material sample of about 5 m should be supplied.
|Calibration:||According to SCHMIDT factory procedure|
|Accuracy:||±1 % full scale or ±1 graduation on scale|
|Scale diameter:||54 mm|
|Temperature range:||10 – 45 ºC|
|Air humidity:||85 % RH, max.|
|Housing material:||Plastic (POM)|
|Weight, net (gross):||Approx. 200 g (Approx. 600 g)|
Specifications subject to change without notice!
SCHMIDT scales are manufactured according to the most stringent quality requirements. Printed scales are not used. Instead, each scale is individually marked for the instrument involved. This ensures highest quality. Our special procedure makes it possible to provide tension meter ZF2
- calibrated to custom supplied material
- fine tuned to a specific tension range
- other units of measure such as g
